Applicable to decoration as topcoat for various metal products. |
LZM WaterFine Topcoat of Different Color (Natural dry)
I Product overview
◆Category: This product is one-component air-dry colored paint with high-grade acrylic resin as film material;
◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;
◆Characteristics:
※Water is the disperse medium of this product, no fire point at normal temperature, combustion and detonation is unlikely to occur;
※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union;
※Fine adhesion, weatherability, protection and decoration performance.
※Volatile water is less than organic solvent, so floor space is greater than oily paint under the same thickness for construction.
II Scope of application: apply for metal surfaces of light industrial products, electromechanical equipment, meters, vehicles, etc.
III Technical data (typical data)
Item |
Indicator |
Color and appearance |
Thick liquid of different color |
Fineness |
≤20μm |
Viscosity (paint-4cup) |
≥60s |
Solid content (120°C /2 hour) |
≥40% |
Adhesion (Circle method) |
≤class 1 |
Impact strength |
≥50 cm.kg |
Pencil hardness |
≥HB |
Flexibility |
≤1 mm |
Resistivity against water (Tag water) |
No blistering or peeling, allow minor discoloration in 96h |
Brine resistance (3%NaCl solution) |
No blistering or peeling, allow minor discoloration in 48h |
Time of drying (23±2°C, relative humidity≤80%) |
Surface dry≤40min/actually dry≤48h/hard dry ≤7days |
(Note: test conditions for resistance to brine and salt spray: 1. Substrate: degreased and polished cold-rolled plate; 2. Coating: spray coating with epoxy zinc rich primer twice + epoxy micaceous iron intercoat twice; 3. Drying: air dry at normal temperature for 7 days.)
IV Construction for reference
◆Surface treatment: wipe off the impurity, for example, floating dust, rust, oil stain, etc. to keep the surface clean and dry;
◆Form of construction work: spray coating or brush with soft wool brush;
◆Thinner: purified water or clean tap water;
◆Dilution ratio: add water by 5%~15% of the paint weight, or adjust as the case may be;
◆Applicable viscosity: immersion 25~30s (paint-4cup, 23±2°C);
◆Type of drying: naturally dry at normal temperature or bake at a temperature of 80°C~90°C for 15~20 min;
◆Coating thickness: 15μm ~25μm (dry film thickness, single layer).
VII Attentions
◆Difference in the level of processing metal substrate is referred to final effect and barrier property of the film coating;
◆Coating it as quickly as possible after substrate done, secondary coating can be processed on the surface dried paint film;
◆Do not work at a temperature below 5°C, relative humidity≥85%;
◆Do not work outdoors when it is wet. If started, please cover the wet paint film with a canopy.
◆Keep the product in a cool and ventilate place (5°C~45°C). The validity is 1 year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.
VI Packing and shipping
◆Packing: 20kg/barrel;
◆Shipping: transport as non-hazardous goods. |
LZD WaterFine Primer of Different Color (Natural dry)
I Product overview
◆Category: This product is one-component air-dry colored paint with high-grade resin as film material;
◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;
◆Characteristics:
※Water is the disperse medium of this product, no fire point at normal temperature, combustion and detonation is unlikely to occur;
※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union;
※Fine adhesion, wear resistance, and rust resistance, and favorable compatibility with a majority of waterfine and oil primers;
II Scope of application: apply for metal surfaces of light industrial products, electromechanical equipment, meters, vehicles, etc.
III Technical data (typical data)
Item |
Indicator |
Color and appearance |
Thick liquid of different color |
Fineness |
≤50μm |
Viscosity (paint-4cup) |
≥80s |
Solid content (120°C /2 hour) |
≥50% |
Adhesion (Circle method) |
≤class 1 |
Impact strength |
≥50 cm.kg |
Pencil hardness |
≥HB |
Flexibility |
≤1 mm |
Resistivity against water (Tag water) |
No blistering or peeling, allow minor discoloration in 96h |
Brine resistance (3%NaCl solution) |
No blistering or peeling, allow minor discoloration in 48h |
Time of drying (23±2°C, relative humidity≤80%) |
Surface dry≤30min/actually dry≤48h/hard dry ≤7days |
(Note: test conditions for resistance to brine and salt spray: 1. Substrate: degreased and polished cold-rolled plate; 2. Coating: spray coating with epoxy zinc rich primer twice + epoxy micaceous iron intercoat twice; 3. Drying: air dry at normal temperature for 7 days.)
IV Construction for reference
◆Surface treatment: wipe off the impurity, for example, floating dust, rust, oil stain, etc. to keep the surface clean and dry;
◆Form of construction work: spray coating or brush with soft wool brush;
◆Thinner: purified water or clean tap water;
◆Dilution ratio: add water by 5%~15% of the paint weight, or adjust as the case may be. The maximum quantity should be less than 25%;
◆Applicable viscosity: spray: 25~35s/brush: 50~60s (paint-4cup, 23±2°C);
◆Type of drying: naturally dry at normal temperature or bake at a temperature of 80°C~90°C for 15~20 min;
◆Coating thickness: 15μm ~25μm (dry film thickness, single layer).
VII Attentions
◆Difference in the level of processing metal substrate is referred to final effect and barrier property of the film coating;
◆Coating it as quickly as possible after substrate done, secondary coating can be processed on the surface dried paint film;
◆Do not work at a temperature below 5°C, relative humidity≥85%;
◆Do not work outdoors when it is wet. If started, please cover the wet paint film with a canopy.
◆Keep the product in a cool and ventilate place (5°C~45°C). The validity is 1 year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.
VI Packing and shipping
◆Packing: 25kg/barrel;
◆Shipping: transport as non-hazardous goods.
|
LZD&M WaterFine Primer-Topcoat Paint of Different Color (Natural dry)
I Product overview
◆Category: This product is one-component air-dry colored paint with high-grade acrylic resin as film material;
◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;
◆Characteristics:
※Water is the disperse medium of this product, no fire point at normal temperature, combustion and detonation is unlikely to occur;
※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union;
※Fine adhesion, weatherability and rust resistance;
II Scope of application: apply for metal surfaces of light industrial products, electromechanical equipment, meters, vehicles, etc.
III Technical data (typical data)
Item |
Indicator |
Color and appearance |
Thick liquid of different color |
Fineness |
≤25μm |
Viscosity (paint-4cup) |
≥80s |
Solid content (120°C /2 hour) |
≥30% |
Adhesion (Circle method) |
≤class 1 |
Impact strength |
≥50 cm.kg |
Pencil hardness |
≥HB |
Flexibility |
≤1 mm |
Resistivity against water (Tag water) |
No blistering or peeling, allow minor discoloration in 96h |
Brine resistance (3%NaCl solution) |
No blistering or peeling, allow minor discoloration in 48h |
Time of drying (23±2°C, relative humidity≤80%) |
Surface dry≤30min/actually dry≤48h/hard dry ≤7days |
(Note: test conditions for resistance to brine and salt spray: 1. Substrate: degreased and polished cold-rolled plate; 2. Coating: spray coating with epoxy zinc rich primer twice + epoxy micaceous iron intercoat twice; 3. Drying: air dry at normal temperature for 7 days.)
IV Construction for reference
◆Surface treatment: wipe off the impurity, for example, floating dust, rust, oil stain, etc. to keep the surface clean and dry;
◆Form of construction work: spray coating or brush with soft wool brush;
◆Thinner: purified water or clean tap water;
◆Dilution ratio: add water by 5%~15% of the paint weight, or adjust as the case may be. The maximum quantity should be less than 25%;
◆Applicable viscosity: spray: 20~25s/brushing: 50~60s (paint-4cup, 23±2°C);
◆Type of drying: naturally dry at normal temperature or bake at a temperature of 80°C~90°C for 15~20 min;
◆Coating thickness: 10μm ~20μm (dry film thickness, single layer).
◆Coating area: coat twice: 6-8m2/kg. Specific consumption is subject to the coefficient of roughness, substrate material, form of construction, and so on.
VII Attentions
◆Difference in the level of processing metal substrate is referred to final effect and barrier property of the film coating;
◆Coating it as quickly as possible after substrate done, secondary coating can be processed on the surface dried paint film;
◆Do not work at a temperature below 5°C, relative humidity≥85%;
◆Do not work outdoors when it is wet. If started, please cover the wet paint film with a canopy.
◆Keep the product in a cool and ventilate place (5°C~45°C). The validity is 1 year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.
VI Packing and shipping
◆Packing: 20kg/barrel;
◆Shipping: transport as non-hazardous goods. |
LZD WaterFine Primer of Different Color (Baking dry)
I Product overview
◆Category: This product is one-component air-dry colored paint with high-grade acrylic resin as film material;
◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;
◆Characteristics:
※Water is the disperse medium of this product, no fire point at normal temperature, combustion and detonation is unlikely to occur;
※Fine adhesion, weatherability, protection and decoration performance.
※Volatile water is less than organic solvent, so floor space is greater than oily paint under the same thickness for construction.
※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union;
II Scope of application: apply for metal surfaces of light industrial products, electromechanical equipment, meters, vehicles, etc.
III Technical data (typical data)
Item |
Indicator |
Color and appearance |
Thick liquid of different color |
Fineness |
≤20μm |
PH value |
8.0~9.0 |
Viscosity (paint-4cup) |
≥45s |
Solid content (120°C /2 hour) |
≥35% |
Gloss (60° photometer) |
0~90 |
Adhesion (Circle method) |
≤class 1 |
Impact strength |
≥50 kg.cm |
Pencil hardness |
≥2H |
Flexibility |
≤1 mm |
Brine resistance (3%NaCl solution) |
(Single layer paint film) no blistering or peeling in 120 h |
Salt spray resistance (neutral salt spray test) |
(Single layer paint film) no blistering or peeling in 96 h |
Alcohol resistance (wipe back and forth 30 times) |
No discoloration |
(Note: test conditions for resistance to brine and salt spray: 1. Substrate: degreased and polished cold-rolled plate; 2. Coating: spray coating, dry film 20μm~25μm; 3. Drying: 145±2°C, baking at constant temperature for 30min.)
IV Construction for reference
◆Surface treatment: wipe off the impurity, for example, floating dust, rust, oil stain, etc. to keep the surface clean and dry;
◆Form of construction work: spray coating or brush with soft wool brush;
◆Thinner: purified water or clean tap water;
◆Dilution ratio: add water by 10%~25% of the paint weight, or adjust as the case may be;
◆Applicable viscosity: spray: 25~30s (paint-4cup, 23±2°C);
◆Type of drying: 145±2°C (low temperature form)/ 175±2°C (high temperature form); bake at constant temperature for 30min;
◆Coating thickness: 15μm ~25μm (dry film thickness, single layer).
VII Attentions
◆Difference in the level of processing metal substrate is referred to final effect and barrier property of the film coating;
◆After coating, let work pieces sit in dustless environment for 3~8min before accessing baking equipment;
◆Keep the product in a cool and ventilate place (0°C~45°C). The validity is 1 year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.
VI Packing and shipping
◆Packing: 20kg/barrel;
◆Shipping: transport as non-hazardous goods. |
|
|
|
|
